Grafana + Prometheus 모니터링 구축

Prometheus 다운로드

1. wget https://github.com/prometheus/prometheus/releases/download/v2.35.0/prometheus-2.35.0.linux-amd64.tar.gz
2. tar xvzf prometheus-2.35.0.linux-amd64.tar.gz

Prometheus 실행

nohup ./prometheus --config.file=prometheus.yml >> ./prometheus_run.log 2>&1 &

야믈파일에 적힌 config 값들을 토대로 prometheus 실행됨

address=0.0.0.0:9090

Grafana 다운로드

1. wget https://dl.grafana.com/enterprise/release/grafana-enterprise-8.5.3-1.x86_64.rpm
2. sudo yum install grafana-enterprise-8.5.3-1.x86_64.rpm

Grafana 실행

1. sudo systemctl daemon-reload
2. sudo systemctl start grafana-server
3. sudo systemctl status grafana-server
   1. grafana-server.service - Grafana instance
         Loaded: loaded (/usr/lib/systemd/system/grafana-server.service; disabled; vendor preset: disabled)
         Active: active (running) since Wed 2022-05-25 17:15:47 KST; 5s ago
           Docs: http://docs.grafana.org
       Main PID: 15426 (grafana-server)
          Tasks: 9
         CGroup: /system.slice/grafana-server.service
                 └─15426 /usr/sbin/grafana-server --config=/etc/grafana/grafana.ini --pidfile=/var/run/grafana/grafana-
4. sudo systemctl enable grafana-server
